| Specification | Details |
|---|---|
| Model | IT7100E |
| Display Size | 10.1 inch TFT LCD Touch Screen |
| Resolution | 1024 × 600 pixels |
| Touch Type | Resistive Touch Panel |
| CPU | ARM Cortex-A8, 1 GHz |
| RAM | 256 MB DDR3 |
| Flash Memory | 256 MB |
| Operating System | Linux |
| Ethernet Port | 1 × 10/100 Mbps Ethernet |
| Serial Ports | COM1 (RS422/RS485), COM2 (RS232), COM3 (RS485) |
| USB Ports | 1 × USB 2.0, 1 × Mini USB |
| SD Card | Supported |
| Communication Protocols | Modbus RTU/TCP, MQTT, OPC UA, VNC |
| Display Colors | 24-bit True Color (16.7 Million Colors) |
| Brightness | 350 cd/m² |
| Backlight | LED |
| Backlight Life | 30,000 Hours |
| RTC | Built-in Real Time Clock |
| Power Supply | 24 VDC ±20% |
| Rated Current | 300 mA |
| Protection Class | Front IP65, Rear IP20 |
| Dimensions | 271 × 213 × 36 mm |
| Operating Temperature | -10°C to +55°C |
Price:
₹ 27,216.00
Mechtrace by CS Bakery Solutions
