| Usage/Application | Industrial |
| Color | Black |
| Power Supply Voltage | 5...30V DC |
| Operating Temperature Range | -10...70 DegreeC |
| Total Resolution | 1024imp/revol. |
| Features | shaft 8mm |
| Availability | In Stock |
Shaft Outer Diameter: Ø8 mm
Resolution: Varies (e.g., 1 P/R, 1024 P/R, 2500 P/R)
Output Phases: A, B, Z (with complementary outputs)
Control Output: Line Driver or Voltage (depending on model)
Power Supply: 5 VDC ±5% (ripple P-P: max. 5%)
Max. Response Frequency: 300 kHz
Max. Allowable Revolution: 5000 rpm
Starting Torque: Max. 70 gf·cm (0.00686 N·m)
Connection Type: Axial cable or axial cable connector type
Protection Structure: IP50 (IEC standard)
Operating Temperature: -10 to 70°C
Storage Temperature: -25 to 85°C
Ambient Humidity: 35% to 85% RH (storage: 35% to 90% RH)
Weight: Approx. 275–363 g (depending on model)
