Bentone ST120 Burner Motor
Bentone ST120 Burner Motor
| Brand: Bentone |
Bentone
Bentone was founded in Ljungby in 1954 by Karl-Erick Johansson and already from the start Bentone were focusing on optimizing burners and always perform better than our competitors and our big secret was to use as little fuel as possible and create a very nice oil mist from the nozzle and create a mix of oil and air for a perfect combustion. Bentone was one of the pioneers in early combustion technology and since then we have continuously developed new technology.
The Bentone ST120 Burner Motor is a highly reliable and energy-efficient motor designed specifically for use in oil and gas burners. Its robust construction and advanced engineering ensure smooth, consistent operation even in demanding industrial and commercial environments. The motor drives the burner fan and fuel pump, enabling proper combustion air delivery and fuel flow regulation.
The ST120 burner motor is engineered for durability, with a thermally protected design to withstand high operating temperatures and continuous use. It is optimized for low noise and vibration, providing efficient performance with minimal maintenance requirements.
Technical Specifications
Electrical Specifications:
- Voltage: 230 V AC (±10%)
- Frequency: 50/60 Hz
- Power Rating: 90–120 W (depending on configuration)
- Current: ~0.8 A
Performance:
- Speed: 2800–3000 RPM
- Duty Cycle: Continuous (S1)
- Insulation Class: F
- Protection Class: IP54
Mechanical Design:
- Shaft Diameter: 8 mm
- Shaft Length: 20 mm
- Mounting: Flange-mounted
- Dimensions: Approx. 190 mm (L) x 100 mm (W) x 120 mm (H)
- Weight: ~3.5 kg
Operating Conditions:
- Ambient Temperature: -20°C to +40°C
- Humidity: <90% non-condensing
- Noise Level: <60 dB(A)
Compatibility:
- Suitable for Bentone BFG, BF, and other compatible burner models.
- Designed for oil and gas burner systems.
Safety and Compliance:
- Thermally Protected: Prevents overheating.
- Certified to meet global standards for safety and performance.
- Reliable Performance: Delivers consistent torque and speed for optimal burner operation.
- Durable Construction: Designed to endure high temperatures and continuous use.
- Energy Efficient: Consumes minimal energy, reducing operational costs.
- Quiet Operation: Engineered for low noise and vibration levels.
- Ease of Installation: Compact and flange-mounted for quick and easy integration.
