Technical specifications
Specification | Details |
|---|---|
Manufacturer | OMRON |
Series | E2B |
Model number | E2B-M12KN08-WP-B1 |
Sensor type | Inductive proximity sensor |
Supply voltage | 10–30 V DC |
Sensor size | M12 |
Sensing distance | 8 mm |
Output type | PNP |
Switching mode | Normally Open (NO) |
Connection | Pre-wired cable |
Cable length | 2 m |
Housing material | Nickel-plated brass |
Mounting type | Non-flush / unshielded |
Protection rating | IP67 |
Overall sensor length | 47 mm |
Thread length | 23 mm |
Operating temperature | −25°C to +70°C |
