Combined mounting of 3 port valve and 5 port valve is possible
●Power consumption: 0.1 W (with power saving circuit)
●A wide variety of manifold options such as aluminum body manifold, DIN rail, stacking type manifold
●Manifold type No.: SS5Y3，SS5Y5，SS5Y7，SS5Y9
●Power consumption: 0.1 W (with power saving circuit)
●A wide variety of manifold options such as aluminum body manifold, DIN rail, stacking type manifold
●Manifold type No.: SS5Y3，SS5Y5，SS5Y7，SS5Y9
| Field | Value | Value Details |
|---|---|---|
| Series | 7 | SY7000 |
| Type Of Actuation | 1 | 2 Position Single |
| Coil Specifications | - | Standard |
| Rated Voltage | 5 | 24 VDC |
| Electrical Entry | D | DIN Terminal |
| Light/Surge Voltage Suppressor | Z | With Light/Surge Voltage Suppressor |
| Manual Override | - | Push-turn Locking Type |
| A/B Port Size | 02 | 1/4 |
| Thread Type | - | Rc |
| Bracket | - | None |
| Made To Order | - | Standard |
