| Category | Specification |
|---|---|
| Design | Directly actuated poppet valve |
| Type of actuation | Electric |
| Sealing principle | Soft |
| Mounting position | Optional |
| Type of mounting | In-line installation |
| Connection – Process valve | G1/4 |
| Electrical connection | Plugs |
| Electrical standard | To EN 175301-803, square design |
| Nominal size | 3 mm |
| Valve function | 2/2-way, closed, monostable |
| Manual override | None |
| Flow direction | Non-reversible |
| Medium | Compressed air (ISO 8573-1:2010 [7:4:4]), Inert gases, Mineral oil, Water, Neutral fluids, Other media on request |
| Pressure difference | 0 MPa / 0 bar / 0 psi |
| Medium pressure range | 0–1.5 MPa / 0–15 bar / 0–217.5 psi |
| Max. viscosity | 25 mm²/s |
| Media temperature | -10 °C to 140 °C |
| Ambient temperature | -10 °C to 80 °C |
| Flow rate (Kv) | 0.25 m³/h |
| Switching time ON | 8 ms |
| Switching time OFF | 25 ms |
| Characteristic coil data | 220/230 V AC, 50/60 Hz, Pick-up power 20.0 VA, Holding power 15.0 VA |
| Insulation material class | F |
| Permissible voltage fluctuations | +15% / -10% |
| Duty cycle | 100% |
| Type of reset | Mechanical spring |
| Type of piloting | Direct |
| Symbol | 00992979 |
| Note on materials | RoHS-compliant |
| Material – Housing | Brass (CW617N) |
| Material – Seals | FPM |
| Product weight | 300 g |
| CE mark compliance | EU EMC Directive, EU Low Voltage Directive, EU RoHS Directive |
| UKCA marking compliance | UK RoHS instructions, UK regulations for electrical equipment |
| Degree of protection | IP65 |
| Corrosion resistance class (CRC) | 1 – Low corrosion stress |
